Giới thiệu Bo mạch chủ Mainboard AMD Colorful C. A68M - K Plus V15
Sản phẩm Bo mạch chủ Mainboard AMD Colorful C. A68M - K Plus V15
| Sản phẩm | Bo mạch chủ Mainboard Colorful C.A68M-K plus V15 |
|---|---|
| Chipset | AMD A68H chipset |
| Processor CPU | Support FM2/FM2+ AMD APUs（TDP:100W) |
| Memory | 2 memory slots，support DDR 3 dual channel 1066/1333/1600/1866(OC) /2133(OC) MHz memory |
| Graphics | 1 PCIE 2.0/3.0 X16 slot |
| Board I/O | 2xPS2 ports; 1x (VGA+ HDMI) ports; 4xUSB 2.0 ports; 1xRJ45 1000M LAN; 3 audio ports; 1x9pin USB 2.0 header ;1x19pin USB 3.0 header, 1x9pin COM header |
| Expansion Slots | 1 PCIE 2.0/3.0 X16 slot, 1 PCI slot |
| BIOS | 32M UEFI |
| Power Management | 5-phase power supply,support 100W TDP |
| Hardware Monitor CPU Fan speed Controlled，SYSTEM Fan speed Monitoring,CPU Temperature Monitoring，System Temperature Monitoring，and Voltage monitoring | |
| LAN | RTL8111F 1000M LAN |
| Audio | ALC662 6-CH audio chipset |
| Configuration | 170*225mm mATX |
